MLE192C2-24UD

Class 2 Electronic Outdoor UNIV 5 in 1 dimming
Black Powder Coated Steel Enclosure

E498696	Conforms to UL STD. 8750
	Certified to CSA STD. C22.2 № 250.13
	model MLE192C2-24UD

Electrical Parameters

Input Voltage:	110-277V 50/60Hz
Max. input current:	2.3A at full load
Output voltage without load:	24.1VDC
Output voltage fully loaded:	24VDC
Max. Total Wattage:	192W	Max. per circuit:96W
Max. Output Current:	4A per circuit.
Efficiency:	90%
Load regulation:	1%
Ripple:	5%

PICTURE MAY NOT REPRESENT ACTUAL ITEM. PLEASE REFER TO PRODUCT DESCRIPTION.
For Specification Sheet, Click Here - PDF
For Installation Sheet, Click Here - PDF
